Electric vehicles (EVs) are transforming the way we move. The sales of these vehicles is surging around the world with battery technology advancement and environmental awareness. Along with their benefits, EVs have also introduced new challenges, particularly in fire safety. EV fires are rare but can be very complex because of their unique characteristics like prolonged burn times, reignition risks, and chemical hazards that require a specialized approach.
For fire investigators, understanding EV fires is important. In this guide, we’ll take a look into the science, techniques, and tools you need to handle EV fire investigations effectively. Whether you’re analyzing the cause of a battery fire or presenting findings in court, this guide will provide you with the knowledge you need to handle EV fire scenes confidently.
What Are EV Fires?
EV fires involve vehicles powered by electric motors, predominantly using lithium-ion batteries as their energy source. These fire incidents are different from traditional vehicle fires due to the unique properties of their power systems. Unlike internal combustion engines, which rely on flammable liquids like gasoline, EV fires often result from failures within the battery itself or its related components.
Lithium-ion batteries store a large amount of energy in a compact space. When this energy is released uncontrollably, it can result in thermal runaway—a process where heat rapidly escalates, which then leads to intense and prolonged fires. Because of these complexities, you’ll need an understanding of general fire dynamics as well as advanced battery-specific technical knowledge to investigate EV fires.
In 2023, nearly one in five cars sold was electric. With projected sales expected to grow year on year, it’s more important than ever for fire investigators to understand the science behind fire incidents involving EVs. Although EV fires are rare, they can be catastrophic, both in terms of physical damage and investigative complexity. These fires are often more challenging to extinguish and can reignite long after initial suppression.
How EV Fires Differ from Traditional Vehicle Fires
EV fires differ significantly from fires in traditional internal combustion engine (ICE) vehicles. Understanding these differences will help you figure out the right investigation approaches, fire suppression techniques, and safety protocols.
| Feature |
EV Fires |
Traditional Vehicle (ICE) Fires |
| Prolonged Burn Times |
Can reignite hours or days after suppression due to residual energy in battery cells. Continuous monitoring with tools like thermal imaging is crucial. |
Burn out relatively quickly once fuel (e.g., gasoline) is consumed. Reignition is rare. |
| High Temperatures and Explosions |
Generate temperatures exceeding 1,200°F, with potential for explosions caused by pressure build-up in battery packs. |
Typically reach around 600°F. Explosions are less common but may occur with fuel tank ruptures. |
| Chemical Hazards |
Release toxic gases like hydrogen fluoride, posing significant risks to responders and investigators. Proper ventilation and respiratory protection are essential. |
Produce smoke and fumes, but generally lack the severe toxicity of lithium-ion battery byproducts. |
| Distinct Burn Patterns |
Leave burn patterns concentrated in battery compartments or electrical systems, aiding in pinpointing the fire’s origin. |
Burn patterns are often linked to fuel sources, such as engine components or fuel lines. |
Prolonged Burn Times
Unlike gasoline fires, which often burn out relatively quickly once fuel is consumed, EV fires can reignite hours—or even days—after suppression. This is due to residual energy stored within the battery cells, which can trigger reignition. This is why it’s important to continuously monitor the fire and use tools like thermal imaging.
High Temperatures and Explosions
Lithium-ion battery fires generate temperatures of over 1,200°F, compared to 600°F for ICE fires. These extreme temperatures can cause explosions as pressure builds within the battery pack.
Class 10 Hazard? Top 5 Battery Explosions
Chemical Hazards
Burning lithium-ion batteries release toxic gases, including hydrogen fluoride, which pose severe risks to responders and investigators. Respiratory protection and proper ventilation are important when investigating these incidents.
Distinct Burn Patterns
EV fires often leave unique burn patterns concentrated in the battery compartment or around electrical systems. Understanding these patterns can help you pinpoint the fire’s origin and progression.
Causes of EV Fires
There can be many causes of EV fires, and sometimes they can be interconnected. This is why it’s important for you to evaluate all possibilities carefully. Here’s a look at a few leading causes of EV fires.
Manufacturing Defects
Defective batteries, faulty wiring, or improper assembly can lead to overheating and fire. For example, GM conducted a recall of Bolt EVs and EUVs in 2022 due to manufacturing defects in the battery cell that increased a risk of battery fires. As with anything that’s mass manufactured, there’s a risk of manufacturing defects even with EVs.
Thermal Runaway
Battery thermal runaway occurs when heat from one battery cell triggers neighboring cells, leading to quick fire escalation. Physical damage or improper charging can often trigger this process.
Charging-Related Incidents
Faulty charging stations, damaged connectors, or improper handling can overload batteries, which can lead to overheating and fire. You should carefully examine the condition of charging systems during fire analysis.
External Factors
External conditions such as collisions, exposure to water, or extreme temperatures can also compromise battery integrity, leading to fires. These factors often complicate investigations as they may mask the initial cause.
How EV Fires Behave
When you’re investigating an EV fire, you’ll often notice unique behaviors that set it apart from traditional vehicle fires. Here’s what you need to know about fire behavior when it comes to electric vehicles.
Thermal Runaway Dynamics
Thermal runaway is one of the most common components in EV fire behavior. It begins when a single lithium-ion cell overheats due to an internal or external trigger, such as a short circuit, overcharging, or physical damage. This overheating causes the electrolyte within the cell to vaporize, releasing flammable gases. The pressure and heat build-up can lead to an explosive failure of the cell, igniting nearby cells in the battery pack.
This self-propagating chain reaction is particularly dangerous because it accelerates quickly, often within seconds, making early detection crucial. You should be aware of the audible and visual indicators of thermal runaway, such as:
- Popping or hissing sounds: These are caused by the release of gases as cells rupture.
- Bright flames or flashes: These are emitted as the flammable gases ignite.
- Dense, white smoke: This is a mixture of vaporized electrolytes and combustion byproducts.
Recognizing these signs can help you understand the fire's progression and identify the point of origin. Detailed analysis of the battery remains can often reveal the cell or group of cells where the thermal runaway began, providing important evidence for the investigation.
Heat Propagation in EV Batteries
Electric vehicle battery packs are designed with safety in mind. They use compartmentalization and thermal barriers to limit heat spread during failures. These barriers include:
- Heat shields: Protective materials placed between cells to absorb and redirect heat.
- Ventilation systems: Designed to expel heat and gases safely away from the vehicle.
- Fire-resistant materials: Used in the battery casing to delay or prevent external fire spread.
Even with these safety designs, once these safeguards fail due to thermal runaway, an external fire, or a high-energy impact, heat propagation can accelerate uncontrollably. When this happens, multiple cells ignite in a domino effect, rapidly increasing the intensity and duration of the fire.
When investigating these scenes, it’s important to pay special attention to the structural integrity of the battery pack to determine how heat propagation occurred. Here’s what you should inspect:
- Cell-to-cell damage: Look for evidence of cascading failure across cells.
- Barrier breaches: Identify where heat or flames penetrated thermal shields.
- Battery pack vents: Assess whether gases and heat were expelled as intended or if they contributed to the fire's intensity.
Understanding heat propagation helps you piece together the sequence of events to understand whether the fire's spread was due to design flaws, external factors, or improper handling of the vehicle.
Unique Hazards of Lithium-Ion Batteries
Lithium-ion batteries are used widely because they’re efficient. But they also come with unique challenges during and after a fire. When damaged, they release a combination of flammable gases, including hydrogen, carbon monoxide, and hydrofluoric acid. These byproducts are not only hazardous but can also intensify the fire.
Here are a few important risk factors to know of during combustion:
- Toxic Gas Emissions: Hydrogen fluoride (HF), a highly corrosive and toxic gas, can cause severe respiratory and skin damage even in small concentrations. Carbon monoxide, a common byproduct of combustion, adds to the toxic load at the scene.
- Explosions: As heat and pressure build within sealed cells, they can burst violently, propelling fragments of the battery casing and creating secondary hazards.
Even post-fire, there are other hazards to deal with:
- Reignition Risks: Damaged batteries can reignite hours or even days after the initial fire due to residual energy within undamaged cells.
- Corrosive Residues: Electrolyte residues left behind after combustion can corrode materials and harm investigators handling evidence.
Because of these hazards, it's important to prepared and be cautious when investigating EV fires
Investigation Techniques for EV Fires
Investigating EV fires requires a systematic approach that prioritizes safety and accuracy. Here are a few techniques you can use to improve the accuracy of your investigations.
Secure the Scene
Securing the scene is the first and most important step in any EV fire investigation. Electric vehicle fires present unique challenges, including reignition risks, high temperatures, and toxic gases, which you must manage to ensure your safety and preserve evidence.
Start by establishing a perimeter:
- Safety Zone: Create a buffer zone around the vehicle to protect investigators and prevent bystanders from entering hazardous areas. The perimeter should account for potential battery explosions or the release of toxic fumes.
- Environmental Considerations: Assess nearby structures, vegetation, or other vehicles that may have been affected by the fire or could pose additional hazards.
Residual heat within the battery pack can reignite fires hours or even days after suppression. This makes it important to monitor the scene continuously. Use thermal imaging cameras to identify hot spots or areas where heat is still being emitted from the battery pack. These areas may indicate incomplete suppression or undamaged cells retaining energy.
Identify the Ignition Point
Determining the ignition point is a foundation of fire investigations, and this is especially challenging in EV fires due to the complexity of the battery system and external factors.
Burn patterns provide important clues about the fire’s origin and progression.
- Battery Compartment: Examine the battery pack for breaches, melted casings, or heat damage that may help identify the fire’s starting point.
- Electrical Components: Look for charring or damage around high-voltage cables, charging ports, and control systems, which could indicate an electrical fault or short circuit.
- Accelerant-Like Patterns: In some cases, burn patterns resembling those caused by accelerants may be observed near the battery pack. These are often the result of vaporized electrolytes igniting rather than external accelerants.
Understanding how the fire spread is crucial for verifying the ignition point. Observe the direction of heat and flame movement to trace the fire back to its source. Consider how airflow, whether natural or from firefighting efforts, may have influenced the fire’s progression.
Reconstruct the Fire Timeline
Understanding the sequence of events leading to an EV fire can help you get to the cause. Here’s how you can piece together the timeline:
- Telematics and Data Logs: Modern EVs continuously record vehicle data, including battery health, charging sessions, and error codes. Use this data to reveal anomalies, such as overheating or voltage irregularities, that occurred before the fire.
- Surveillance Footage: If the incident occurred near a charging station, parking lot, or public road, nearby security cameras or dashcams may capture key moments like ignition or early fire behavior.
- Witness Testimonies: Speaking with EV owners, bystanders, or first responders can provide additional clues about unusual smells, noises, or vehicle performance issues they may have observed before the fire.
Collect Evidence
Evidence collection requires meticulous attention to detail to ensure admissibility in legal proceedings. Here are a few things to keep in mind when collecting and preserving evidence related to EV fires:
- Battery Remnants: Secure damaged battery cells, modules, and casings. Note their position relative to the vehicle and document any visible damage or deformities.
- Charging Equipment: Collect the charging cable, plug, and any associated connectors. Look for signs of arcing, overheating, or wear that could indicate a failure in the charging system.
- Vehicle Components: Gather any other vehicle parts affected by the fire, such as wiring harnesses, control modules, or insulation materials.
- Photographic Evidence: Take high-resolution photos of the entire scene, focusing on critical components like the battery pack and burn patterns.
- Labeling and Storage: Use fireproof containers to store evidence, particularly battery cells, to prevent further damage or reignition.
- Chain of Custody Records: Maintain detailed records of who handled the evidence and when, ensuring its integrity throughout the investigation process.
Use Telematics Data
Most EVs store real-time data about battery performance and charging history, which can provide critical clues about the fire’s origin. These data logs are invaluable for understanding the conditions leading up to the fire. Here’s what telematics data can reveal:
- Battery Performance: Logs often include information about temperature fluctuations, voltage levels, and current flow within the battery pack. Anomalies in these readings can indicate potential issues, such as overheating or short circuits.
- Charging History: Data about recent charging sessions, including location, duration, and power levels, can help identify whether the fire was related to improper charging practices or faulty equipment.
- Vehicle Events: Sudden deceleration, impacts, or alerts triggered by the battery management system (BMS) may provide clues about external factors contributing to the fire.
You’ll need to work with the vehicle manufacturer to get access to this data. Use tools designed to analyze vehicle event logs for detailed visualizations of pre-fire events. Cross-referencing telematics data with physical evidence, such as burn patterns and battery damage, can strengthen your investigation conclusions.
Work with Forensic Specialists
It’s best to work with specialists in different fields to ensure you’re not missing out on any important evidence:
- Battery Engineers: Work with engineers who understand the intricacies of lithium-ion batteries and battery management systems (BMS). They can help identify design flaws or operational issues.
- Forensic Chemists: Work with chemists to analyze residues and gases for chemical signatures unique to lithium-ion fires.
- Digital Forensics Experts: Partner with digital analysts to extract and interpret telematics and onboard vehicle data, which can provide critical insights into pre-fire conditions.
Safety Considerations for Investigators
Safety is important when dealing with EV fires. These incidents pose unique risks that require specialized precautions.
- Use full protective gear, including respiratory protection, to guard against toxic fumes.
- Batteries can remain volatile. Use insulated tools and non-conductive barriers.
- Water alone may not be enough. Specialized extinguishing agents designed for lithium-ion fires may be necessary.
Modern tools and technologies are transforming the way EV fires are investigated. Use these innovations to increase the efficiency and accuracy of your investigations.
| Tool |
Purpose |
| Thermal Imaging Cameras |
Detects residual heat in battery cells or vehicle structures. |
| 3D Scene Mapping |
Digitally recreate fire scenes for analysis and presentation. |
|
Gas Chromatography
|
Identify chemical residues in burned battery packs. |
| Telematics Analysis Software |
Extract and interpret onboard data logs for cause analysis. |
The Future of EV Fire Investigations
Electric vehicle fires continue to be a major challenge for fire investigators, requiring a blend of traditional skills and advanced tools. But you can ensure accurate analysis of the scene by understanding the unique dynamics of EV fires.
Continue to read emerging information about these vehicles and talk to other investigators to learn more about the techniques they use. Sharing knowledge is the best way for everyone in the industry to collectively improve their expertise.
